JIS L1096 Leather Rubbing Resistance Testing Machine ASO M403 Woven Materials Rubbing Tester

Place of Origin : China

Brand Name : Lonroy

MOQ : 1

Voltage : 220V

Protection Class : IP56

Test speed : 120 times per minute

Dimensions : 45*37*50 cm

Weight : 60 kg

Power Supply : AC 220V, 50Hz

Sample load : 200g - 2000g

Fixture width : 45mm

Maximum fixture spacing : 40mm

Fixture spacing : 0 - 50mm (adjustable)

Surface treatment : American DuPont powder

Curing temperature : 200℃

Material : Non-corrosive structural aluminum, stainless steel

Display control : LED-SLD806 integrated display

Drive motor : Precision drive motor

Certification : ISO ASTM CE

Price : Negotaible

Packaging Details : Wooden package

Delivery Time : 5-8 work days

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 200

Contact Now

JIS L1096 ASO M403 Leather Rubbing Resistance Testing Machine Woven Materials Rubbing Tester

Product Description

Product Description

Rubbing test machine is suitable for the back and forth rubbing resistance test of leather and woven materials.

Fix one end of the sample in the left fixture and the other end in the right fixture. Apply an appropriate pressure for a certain stroke and number of times. The two samples are reciprocally bent and rubbed against each other. After a certain number of times, assess the degree of damage to the samples.

Meet the standards

Standards such as GB/T 8948-2008, JIS L1096, K6404\ASO M403, ASO M403QB/1333-2018, QB/1618-2018, and QB/T 5246-2018, etc.

Features of the instrument

Surface treatment of the machine body: American DuPont powder is used, and the electrostatic spray painting process is adopted. It is cured at a high temperature of 200℃ to ensure that the color does not fade for a long time.

The mechanical components are made of non-corrosive structural aluminum and stainless steel materials.

Precision drive motor, smooth operation, low noise;

LED-SLD806 integrated display control box, menu operation mode

High-precision bearings are selected, ensuring stable rotation and long service life.

One-click automatic testing, independent control, simple and convenient operation;

JIS L1096 ASO M403 Leather Rubbing Resistance Testing Machine Woven Materials Rubbing Tester

Technical Specification

Sample load

200g - 2000g (weight incremental loading)

Fixture width

45mm

Maximum fixture spacing

40mm

Fixture spacing

0 - 50mm (adjustable)

Test speed

120 times per minute

Machine dimensions

45×37×50 cm

Machine weight

Approximately 60 kg

Power Supply

AC 220V, 50Hz

JIS L1096 Leather Rubbing Resistance Testing Machine ASO M403 Woven Materials Rubbing TesterJIS L1096 Leather Rubbing Resistance Testing Machine ASO M403 Woven Materials Rubbing Tester
